Ibanez MIU8 MIDI Interface Unit
Features and Specifications:
- Input: MIDI IN (5 pin DIN) & Remote (6 pin DIN).
- Output: MIDI OUT (8 x 5 pin DIN)
- Power Requirements: DC 9 volts, 170 ma
- Dimensions: 189 mm (W) x 88 mm (D) x 36 mm (7.44" x 3.46" x 1.42")
- Options: AC109 AC Adaptor
- Weight: 480 grams (1.1 lbs)
